4 5
TECHNICAL SPECIFICATIONS
SAFETY GUIDELINES
TECHNICAL SPECIFICATIONS
*CFM: Cubic feet per minute.
1.5
4.0
175
5 U.S. GALLONS (18.9 L)
OIL-LESS
UMC
120 V, 60 Hz, 11.8 A
51 lb 2 oz (23.2 kg)
SJT 16 AWG / 72" (1.83 m)
3.0
RUNNING HP
TANK SIZE
AIR DELIVERY (CFM*) @ 40 PSI
AIR DELIVERY (CFM*) @ 90 PSI
MAXIMUM PRESSURE (PSI)
PUMP DESIGN
MOTOR
POWER
WEIGHT
POWER CORD
SJT 12 AWG / MAXIMUM 30 (9.1 m)EXTENSION CORD
This manual contains information that relates to PROTECTING PERSONAL SAFETY
and PREVENTING EQUIPMENT PROBLEMS.
carefully and understand it thoroughly before using the product. The symbols listed
below are used to indicate this information.
IMPORTANT!
Installation, operation or maintenance information that is important but not hazard related.
It is very important to read this manual
CAUTION!
Potential hazard that may result in moderate injury or damage to equipment.
WARNING!
Potential hazard that could result in serious injury or loss of life.
DANGER!
Potential hazard that will result in serious injury or loss of life.
Safety Advice
1. RISK OF FIRE OR EXPLOSION.
2. RISK OF ELECTRIC SHOCK. Do not expose to rain. Store the compressor indoors. Hazardous
voltage. Disconnect from power source before servicing. Compressor must be grounded. Do not
use grounding adaptors.
3.
4. RISK OF BURSTING. Check the maximum pressure rating in the manual or identification
5.
Do not adjust the pressure switch or safety valve for any reason. They
RISK OF BURSTING.
Do not spray a flammable or combustible liquid or paint
The spray area must be well-ventilated.
Keep compressor at least 20' (6 m) away from spray area. Do not carry and operate the
compressor or any other electrical device near the spray area. Never smoke when spraying.
Use a minimum of 25' (7.6 m) of hose to connect a spray gun to the compressor.
near sparks, flames, pilot lights or in a confined area.
RISK OF PERSONAL INJURY.
Never spray the compressed air or material at self or others.
.
label. The compressor outlet pressure must be regulated so that it does not exceed the
maximum pressure rating. Relieve all pressure in the hose before removing or attaching
accessories. Make sure the regulator is adjusted so that the compressor outlet pressure is
set lower than the maximum operating pressure of the spray gun or tool. Before starting the
compressor, pull the ring on the safety valve to make sure the valve moves freely (see diagram
on page 19). Drain water from tank after each use. Do not weld or repair tank.
have been preset at the factory for this compressor’s maximum pressure. Tampering
with the pressure switch or the safety valve
may cause personal injury or property damage.
model no. 058-1893-2 | contact us 1-800-689-9928
