OPERATING INSTRUCTIONS
15
AIR-POWERED PIN NAILER 058-8122-6
Loading nails
1. Disconnect the tool (1) from the air
supply (2)
(fig A) .
2. Adjust the adjustment lever (1) as per
the size of nail to be inserted
(fig B) .
DANGER!
Potential hazard that will result in serious injury or loss of life.
• Disconnect the tool from the compressed air source before loading nails.
• Do not point the tool towards the operator or other people while changing
nails.
• Do not hold the tool with the trigger pressed while changing nails. Failure
to comply will lead to serious injury or loss of life.
MC-588122-03
1
2
fig A
12
1/2” 5/8” 3/4” 7/8” 8”
15
18
22
25
MC-588122-04
fig B
1
