IMPORTANT INFORMATION
11
AIR-POWERED BRAD NAILER 058-8691-0
Compatible compressors
GUIDELINES FOR PROPER USE AND OPERATION
Be sure to use a proper air compressor with Mastercraft
®
air-powered tools. The compressor that is
being used must be able to supply appropriate amount of pressure (PSI) to the tool.
General use
This Mastercraft
®
Air-powered Brad Nailer includes a die cast aluminum body that is strong and
lightweight, and a comfort grip rubber handle for improved control and comfort, even during
extended use. The tool has a magazine that accepts 18-gauge and 5/8 - 2" (15 to 50 mm) long brad
nails, without adjustment. A hardened one-piece drive blade is provided for professional application,
and an adjusting wheel for controlling the depth of the nails. A touch-strike security system is
included for ensuring safety of the operator. The tool features a 360º air deflector that is adjustable
in any direction, and a quick-release handle for clearing jams. The Air-powered Brad Nailer is best
suited for installing door and window trim, decorative trim, cabinet work, finish paneling, framing,
scribe molding, upholstery, beading, chair rail, flooring works, etc.
Air Compressor
Size & Power
1/3–1 1/3 HP 1 1/2–2 HP 2+ HP
2–6 Gallons
Light-duty and
intermittent use
Light-duty and
intermittent use
Light-duty and
intermittent use
8–11 Gallons
Light-duty and
intermittent use
Heavy-duty and
continuous use
Heavy-duty and
continuous use
15+ Gallons
Medium-duty and
intermittent use
Heavy-duty and
continuous use
Heavy-duty and
continuous use
Wood density Nail size Compressor air pressure
>0.6g/cm
3
<1 1/2" (32mm) brad nails 90 PSI
≥1 1/2" (32mm) brad nails 110 PSI
≤0.6g/cm
3
<1 1/2" (32mm) brad nails 70 PSI
≥1 1/2" (32mm) brad nails 90 PSI
