PARTS LIST
21
AIR-POWERED IMPACT WRENCH 058-9321-6
If any parts are missing or damaged and if you have any questions, please call 1-800-689-9928.
No. Description Qty. No. Description Qty.
1 Bolt M3 X 4 1 23 Reverse valve sleeve 1
2 Hammer case 1 24 Reverse valve seat 1
3 Anvil bushing 1 25 O-ring 48 X 1.8 1
4 Anvil collar 1 26 O-ring 34.2 X 1.5 1
5 O-ring 7.65 X 1.8 1 27 Regulator knob 1
6 Square drive 1 28 Spring 1
7 Hammer pin 2 29 Steel ball 1
8 Hammer dog 2 30 Gasket 1
9 Hammer cage 1 31 Bolt M5 X 88.5 4
10 Washer 1 32 Trigger 1
11 Front washer 1 33 O-ring 4.5 X 1 1
12 Bearing 1 34 Air inlet set 1
13 O-ring 54.5 X 1 1 35 Retainer ring 1
14 Cylinder plate 1 36 Knob cover 1
15 Rotor 1 37 Throttle valve bushing 1
16 Rotor blade 6 38 Valve stem 1
17 Gun body 1 39 Spring 1
18 Cylinder 1 40 O-ring 16 X 2.5 1
19 Bearing 1 41 Spring 1
20 Retainer ring 1 42 Air deflector 1
21 Seal washer 1 43 Washer 1
22 Rear washer 1 44 Air inlet plug 1
