MasterCraft 058-9803-0 User Manual

No.
1
2
Square drive
Housing
Air inlet plug3
No.
4
5
6
Trigger
Power Setting
Always ensure that a suitable air compressor is used with this Mastercraft® Air-powered Impact
Wrench. The compressor should be able to supply a minimal air delivery of 4 CFM @ 90 PSI to
ensure the compressor can run continuously with the Mastercraft Air-powered Impact Wrench. Using
a tool or combinations of tools that together or separately require more than compressor capacity
will reduce performance and could void the guarantee/warranty of compressor or tool.
This Mastercraft® Air-powered Impact Wrench features a twin-hammer mechanism for higher
torque, an adjustable (3 position) torque regulator, and variable speed adjustment. The tool has a
front exhaust. The tool is mainly used for removing and installing nuts and bolts and automotive lug
nuts on tires, and for general assembly work. The sheer power and performance of the tool enables
the operator to tackle the toughest jobs with ease. The tool is durable and economical to use.
General use
Compatible compressor and air tool
GUIDELINES FOR PROPER USE AND OPERATION
Air deflector
Description Description
11
10
model no. 058-9803-0 | contact us 1-800-689-9928
Air Compressor
Size and Power
2 HP 2 1/2 HP 3 HP and more
5–6 Gallons
8–11 Gallons
15 Gallons
and more
Light-duty and
intermittent use
Light-duty and
intermittent use
Medium-duty and
intermittent use
Light-duty and
intermittent use
Medium-duty and
intermittent use
Heavy-duty and
continuous use
Light-duty and
intermittent use
Medium-duty and
intermittent use
Heavy-duty and
continuous use
