MasterCraft 068-0002-6 User Manual

7
ASSEMBLY INSTRUCTIONS
3. Install Right Side Panel (Part 5)
Attach Right Side Panel (Part 5) to
Back Frame (Part 3) making sure
the "Top" of Right Side Panel (Part
5) is on the Solid Hardwood Top
(Part 1). Use three Screws (Part 16)
and Screwdriver (Part 21) to fasten
(Fig. C).
4. Install Middle Panel (Part 8)
Attach the Middle Panel (Part 8) to
the Back Frame (Part 3) and Solid
Hardwood Top (Part 1), as shown in
Fig. D, making sure the "Top" of
Middle Panel (Part 8) is attached on
the Solid Hardwood Top (Part 1).
Again, the “Top” is indicated by a
sticker on one of the vertical
columns. Use three Screws (Part
16) and Screwdriver (Part 21) to
fasten (Fig. D).
Fig. C
Fig. D
