ASSEMBLY INSTRUCTIONS
model no. I contact us 1-800-689-9928068-0005-0
Make sure your floor is free of debris or the cabinet
face is protected before laying the cabinet on its face.
Insert the top edge of top back
panel under the top panel.
3
4
The top edge of the top back panel should be inserted
under the back of the top panel.
Lay the cabinet on its face.
Attach two back panels (4) to the back of the cabinet with fourteen M6 x 16 hex socket head screws (3).
Insert the screws by hand. DO NOT tighten.
•
•
STEP 3 ATTACH THE TOP PANEL
STEP 4 ATTACH THE BACK PANELS
Attach the top panel (20) to the side panels (7 and 19) with eight M6 x 16 hex socket head screws (3).
Insert the screws by hand. DO NOT tighten.
•
3
19
7
20
