STEP 1 ATTACH THE SIDE AND BOTTOM PANELS
ASSEMBLY INSTRUCTIONS
TOOLS REQUIRED FOR ASSEMBLY
• Hex Wrench (23)
• Power Drill (not included)
• Cross-head Screwdriver (not included; magnetic is preferable)
• Measuring Tape (not included)
Please wear gloves during the whole assembly process.
Lay the bottom panel (15) on its front and attach the side panels (1 & 16) to the bottom
panel (15) with two M6 x 16 hex socket head screws (12) through the holes on bottom left
and right corners. DO NOT tighten.
NOTE: Assemble on a flat surface. A piece of cardboard is recommended to keep the product
from being scratched during assembly.
15
1
16
12
Front
Back
