MasterCraft 068-1575-6 User Manual

6
model no. 068-1575-6 I contact us 1-800-689-9928
ASSEMBLY INSTRUCTIONS
STEP 3 INSTALL THE ADJUSTABLE FEET
Install the adjustable feet (13) to the bottom panel (15). Tighten securely with sixteen M6 x 16 hex
socket head screws (12).
•
Screw two M6 x 16 hex socket head screws in the middle through the side panels (1 & 16)
into the bottom panel (15). Tighten securely.
•
STEP 2 ATTACH THE BACK TOP BEAM AND BACK PANELS
Attach the back top beam (20) and back panels (18) to the back. Insert sixteen M6 x 16 hex socket
head screws (12) by hand. DO NOT tighten.
The top edge of the top back panel (18) should be inserted under the back top
beam (20).
18
15
13
12
12
16
20
Insert the top edge of top back
panel under the back top beam.
