5. Common Jack
Plug-in connection for black (negative) test lead.
6. V/
Ω
ΩΩ
Ω
F/ / /CAP Jack
Plug-in connection for red (positive) test lead for all voltage, capacitance, frequency,
resistance and continuity measurements, and diode checks.
7. Range/hold Button
Use to manually select the desired range. When first turned ON, the
multimeter goes into auto-ranging and the word "AUTO" will appear in the upper
left corner of the display. When this button is pressed, a manual range is
selected and the "AUTO" will disappear from the display. Each additional push
causes the range to go higher. When the highest range is reached, the next
push returns the range to its lowest point. To cancel the manual range and
return to auto-ranging, press and hold the button until "AUTO" appears on the
display.
1
