MasterCraft 52-0052-2 - DC Current Specifications; AC Current Specifications; Resistance Specifications; Frequency Specifications

DC CURRENT (A DC)
Range
400 µA
Resolution
100 nA
Accuracy
± (1.2% rdg. + 5 dgts.)
4000 µA 1 µA
40 mA
10 µA
400 mA
100 µA
10 A 10 mA
±
(2% rdg. + 5 dgts.)
AC CURRENT (A AC)
Range Resolution Accuracy
400 µA 100 nA ± (1.2% rdg. + 8 dgts.)
4000 µA 1 µA
40 mA 10 µA
400 mA 100 µA
10 A 10 mA
±
(3% rdg. + 5 dgts.)
RESISTANCE (Ω)
Range Resolution Accuracy
400 Ω 100 mΩ ± (0.8% rdg. + 5 dgts.)
4 KΩ 1 Ω
40 KΩ 10Ω
400 KΩ 100Ω
4 MΩ 1 KΩ
40 M
Ω
10 K
Ω ±
(1.2% rdg. + 10 dgts.)
FREQUENCY (AUTO-RANGING)
Range
4.000 Hz
Resolution
0.001 Hz
Accuracy
± (0.2% rdg. + 3 dgts.)
40.00 Hz 0.01 Hz
400.00 Hz 0.1 Hz
4.000 kHz 1 Hz
40.00 kHz 10 Hz
400.0 kHz 100 Hz
4
