model no. 054-1332-6 | contact us 1-800-689-9928
4
TECHNICAL SPECIFICATIONS
TECHNICAL SPECIFICATIONS
Cordless Drill/Driver Model 5268
Rated Voltage 20 V d.c.
Chuck 3/8” (10 mm) keyless chuck
No-Load Speed 0–600 RPM
Max. Torque 115 in-lb
Clutch 23 + 1 positions
Cordless Drill/Driver Weight (Without Battery) 1 lb 12 oz (0.8 kg)
Battery Type Lithium-Ion
Battery Voltage 20 Volt max* DC
Charger Input 120 Volts, 60 Hz AC only
Optimum Charging Temperature Range 5–40°C (41–104°F)
*Maximum battery voltage without workload; with workload nominal voltage is 18V.

MasterCraft 5268 Specifications

General

Brand	MasterCraft
Model	5268
Category	Drill
Language	English
