KEY PARTS DIAGRAM
PACKAGE CONTENTS:
Cordless drill/driver, 1/2” (13 mm) drill chuck, 1/4” (6.4 mm) hex-drive right-angle adaptor, 1 belt clip, 1
bit holder, 2 single-ended screwdriver bits and instruction manual.
KEY PARTS DIAGRAM
1
No. Description No. Description
1 Two-speed gearbox switch 5 Magnet
2 Torque-adjustment ring 6 Direction-of-rotation selector
3 Keyless chuck 7 LED worklight
4 Variable-speed trigger switch 8 Right-angle adaptor
Before attempting to use this tool, become familiar with all of its operating features and safety
requirements. For optimum performance and safety, read the following operating instructions carefully
before using.
1
2
3
8
4
7
5
6
