18
20V max* LITHIUM-ION COMPACT CORDLESS IMPACT WRENCH - 054-3121-6
PARTS LIST
No. Part No. Description No. Part No. Description
1 5610106000 Tapping Screw 21 5620037000 Screw
2 3126543000 Cover 22 5650007000 Spring Washer
3 3421381000 Front Gear Housing 23 3703951000 Bracket
4 2823347000 Spindle 24 3520658000 Pinion
5 5700226000 Steel Ball 25 2730195000 DC Motor
6 3551809000 Impact Block 26 3126501000 F/R Button
7 5700178000 Steel Ball 27 4870452000 Trigger Switch
8 5650430000 Washer 28 3680140000 Magnet Ring
9 3660528000 Compression Spring 29 4860007000 Inner Wire
10 5690274000 Rubber Ring 30 4860003000 Inner Wire
11 5650163000 Spring Washer 31 4360225000 LED
12 5670319000 Torque Pin 32 3402385000 Contact Receptacle Assembly
13 3520657000 Planet Gear 33 3321620000 Left Housing Assembly
14 3551808000 Spindle 34 3703673000 Bits Holder
15 3520656000 Ring Gear 35 3126500000 LED Cover
16 5650429000 Washer 36 3321616000 Right Housing Assembly
17 5690142000 O Ring 37 5610013000 Tapping Screw
18 5700179000 Bearing 38 3126503000 Lens
19 3126562000 Rear Gear Housing 39 4890709000 PCB Assembly
20 5690007000 O Ring
If the problem remains unsolved after performing the checks described above, call the toll-free
helpline at 1-800-689-9928.
