MasterCraft 55-5504-2 User Manual

1. Transport rollers
(used to transport
workpiece back to infeed
for next planing pass)
2. Reset button
3. ON/OFF switch
4. Workpiece guides
5. Support/infeed roller
6. Mounting holes
7. Measurement scale
8. Carrying handles
9. Cutterhead depth scale
10. Cutterhead depth
adjustment handle
11. UP/DOWN direction decal
12. Motor brushes
13. Cutterhead knife guard
14. Support/outfeed roller
PL002
8
3
4
4
7
6
5
2
1
1011
9
12
V. Know your planer
11
13
14
8

MasterCraft 55-5504-2 Specifications
