IX. Replacement parts
22
MASTERCRAFT
®
12 1/2" THICKNESS PLANER 55-5504-2
When servicing your Mastercraft
®
planer, use Mastercraft
®
replacement parts only. Use of any
other parts may cause product damage. Any and all servicing of the planer should be
performed by a qualified service technician.
WARNING: ANY ATTEMPT TO REPAIR OR REPLACE ELECTRICAL PARTS ON THIS
TOOL MAY BE HAZARDOUS. REPAIRS SHOULD BE DONE BY A QUALIFIED SERVICE
TECHNICIAN.
No. Description Qty No. Description Qty
101 Screw 2
102 Washer 2
103 Cutterhead guard 2
104 Sponge 1
105 Upper guard body 1
106 Screw 4
107 Screw 1
108 Washer 1
109 Link pole 1
110 Handle cover 1
111 Cutterhead handle 1
112 Hex screw 1
113 Pin 4
114 Stopper 4
115 Transport roller 2
116 Blade clalmp 2
117 Blade shaft 1
118 Key 1
119 Spring 4
120 Blade 2
121 Screw 14
122 Bearing 1
123 C-ring 1
124 Wheel 1
125 Nut 1
126 Belt 1
127 Base 1
128 Screw 2
129 Washer 2
130 C-cover 1
131 Sprocket wheel guard 1
132 Screw 2
133 C-ring 1
134 Bearing 1
135 Screw 2
136 Screw 2
137 Sprocket gear 4
138 Chain 2
139 Bushing 1
140 Roller guide 2
141 Screw 8
142 Bearing clamp 4
143 Bearing 4
144 Spring 1
145 Screw 1
146 Scale indicator 1
147 Screw bushing 1
148 Pin 2
149 Washer 4
150 Adjustment nut 2
151 Rotation label 1
152 Wing nut 2
PA RTS LIST FOR THE PLANER BODY (100 SERIES)
