IX. Replacement parts ... continued
24
MASTERCRAFT
®
12 1/2" THICKNESS PLANER 55-5504-2
PA RTS LIST FOR THE PLANER MOTOR (200 SERIES)
No. Description Qty No. Description Qty
201 Motor housing 1
202 Stator 1
203 Cushion 1
204 Screw M5x60 2
205 Logo label 1
206 Bearing 1
207 Armature 1
208 Bearing 1
209 Belt wheel 1
210 Brush holder 2
211 Carbon brush 2
212 Brush cap 2
213 Screw 2
214 Gearbox cover 1
215 Gearbox 1
216 Shaft 1
217 Gear 1
218 Key 1
219 Bearing 2
220 Shaft 1
221 Gear 1
222 Key 1
223 Bearing 2
224 Gear 1
225 Shaft 1
226 Bearing 1
227 Key 1
228 C-ring 2
229 Bearing 1
230 Sprocket wheel 4
231 Dust guard 1
232 Cover 1
233 Block 1
234 Sponge 1
235 Cord bush 2
236 Strain relief 1
237 Screw 4
238 Screw 3
239 Nut 1
240 Washer 2
241 Screw 1
242 Screw 2
243 Protector 1
244 Plug 4
245 Gear pad 3
246 Screw 1
247 Switch 1
248 Pin 2
249 Spring clip 3
250 Power cord 1
201A Motor assembly
207A Armature assembly
