17
LASER DISTANCE FINDER/MEASURING TOOL - 057-4585-0
18
LASER DISTANCE FINDER/MEASURING TOOL - 057-4585-0
Addition and subtraction
The single-distance, area, volume and indirect length can be added or subtracted with the
addition and subtraction functions.
1. Take the first measurement.
2. Press the plus/minus key
to choose addition or subtraction.
3. Take the second measurement.
4. The sum or difference between the measurements will be displayed in the lowest row of the
screen, and the last measurements will be displayed at the same time in the upper row of
the screen.
5. Follow the same method to make additional calculations.
Working with the tripod (available separately)
The use of a tripod is particularly helpful for measuring greater distances. The laser distance
finder/ measuring tool can be screwed onto a commercially available tripod using the 1/4''
thread on the underside of the housing.
1. Mount the tool to the tripod.
2. Set the measuring reference to the thread, the icon shows
.
3. Start to take measurements.
Error signals
The following error signals may appear on the LCD of your tool during measuring:
ERROR CODE CAUSE ACTION
Err 002 Out of range, the measuring range
for this tool is from 0.1 to 50 m.
Take measurement within the
range of 0.1 to 50 m.
Err 004 The temperature is too high. Wait until the laser distance finder/
measuring tool has reached the
operating temperature (-10 to 50ºC)
Err 005 The temperature is too low. Wait until the laser distance finder/
measuring tool has reached the
operating temperature (-10 to 50ºC)
Err 006 Low battery, a reminder to replace
the batteries.
Insert new batteries
Err 007 Strong vibration or the tool was
moved quickly when measuring.
Always keep the tool steady
Err 008 Wrong input: the length of one side
of the right triangle as measured is
longer than the hypotenuse.
Re-measure; the hypotenuse is
always longer than the first side
length
OPERATING INSTRUCTIONS
OPERATING INSTRUCTIONS
