MasterCraft LASER DISTANCE FINDER/MEASURING TOOL User Manual

3
LASER DISTANCE FINDER/MEASURING TOOL - 057-4585-0
4
LASER DISTANCE FINDER/MEASURING TOOL - 057-4585-0
TECHNICAL SPECIFICATIONS
TECHNICAL SPECIFICATIONS
RECOMMENDED USE Indoors
POWER SUPPLY 6 V (4 x 1.5 V AAA
alkaline batteries)
TYPICAL MEASURING RANGE 0.1–50 m*
TYPICAL MEASURING
ACCURACY ±3 mm*
SMALLEST UNIT DISPLAYED 1mm
LASER CLASS II
LASER TYPE λ=635 nm, P≤ 1 mW
AUTOMATIC SWITCH OFF Laser: 20 seconds
Measuring tool: 5 minutes
ESTIMATED BATTERY LIFE Up to 5,000 single
(ALKALINE AAA BATTERIES) measurements
OPTIMUM OPERATING
TEMPERATURE -10 ºC to 50ºC (14° to 122°F)
STORAGE TEMPERATURE -20 ºC to 60ºC (-4 to 140°F)
SIZE 113 x 56.4 x 35 (mm)
WEIGHT (WITHOUT BATTERIES) 0.34 lb. (155 g)
*Important: Under unfavorable conditions, such as in bright sunlight or when measuring poorly
reflecting or very rough surfaces, the tool’s measuring range and accuracy will be reduced. In
such circumstances, please use a reflector (available separately) when taking measurements.
The reflector is a target to be used with the Laser Distance Finder/Measuring Tool to increase
the intensity of the reflected light.
