PROSTAR
209
1
2
3
4
5
6
7
8
9
10
11 12
13
14
13
15
16
17
18
1 OIL PRESSURE GAUGE
2 ENGINE TEMPERATURE GAUGE
3 SPEEDOMETER
4 MULTI-FUNCTION/TACHOMETER
5 CHECK ENGINE LIGHT
6 SPEEDOMETER OR PERFECT PASS GAUGE
7 VOLTMETER
8 FUEL GAUGE
9 HORN
10 ACCESSORY 1 SWITCH
11 ACCESSORY 2 SWITCH
12 COUR TESY LIGHTS SWITCH
13 SPEEDO AJUSTMENT SWITCHES
14 CLOCK ADJUSTMENT SWITCH
15 NAV/ANCHOR LIGHTS SWITCH
16 BILGE PUMP SWITCH
17 BLOWER
18 IGNITION KEY SLOT
LENGTH OF BOAT: .................................... 20’11-1/2”
OVERALL LENGTH W/TRAILER: ................... 22’11-1/2”
WIDTH AMIDSHIP: .................................................... 96”
OVERALL WIDTH W/TRAILER ................................. 100”
HEIGHT W/WINDSHIELD & TRAILER (TA) .................. 79”
HEIGHT W/WINDSHIELD & TRAILER (SA) .......... 80-1/2”
BOAT WEIGHT: ............................ 2,850 LBS. (APPROX.)
SINGLE AXLE TRAILER WEIGHT: ......................... 900 LBS.
T ANDEM AXLE TRAILER WEIGHT: .................... 1,050 LBS.
FUEL CAPACITY: ......................................... 34 GALLONS
CAPA CITY: .............................. 9 PEOPLE OR 1,370 LBS.
AFUEL
TANK
FILLER
B BLOWER
EXHAUST
CSWIM
PLATFORM
D STERN
LIGHT
RECEPTACLE
E STORAGE
UNDER
SUN
PAD
F ENGINE
COMPARTMENT
G T HROTTLE
/
SHIFT
CONTROL
H INSTRUMENT
PANEL
IBOW
LIGHT
JGLOVE
BOX
K BATTERY
(
UNDER
SEAT
)
L DRAIN
PLUG
A
B
C
D
E
F
G
H
I
J
K
L
To Next Page
