MasterCraft Maristar Series

MASTERCRAFT
X-STAR
LENGTH OF BOAT: .............................................. 22’3”
WIDTH AMIDSHIP: ................................................. 100”
BOAT HEIGHT W/WINDSHIELD ................................. 73”
BOAT WEIGHT: ............................ 4,250 LBS. (APPROX.)
FUEL CAPACITY: ......................................... 53 GALLONS
CAPA CITY: ........................... 12 PEOPLE OR 1,770 LBS.
A BLOWER EXHAUST
BSWIM PLATFORM
C FUEL TANK FILLERS
D BATTERIES
E THROTTLE / SHIFT CONTROL
F INSTRUMENT PANEL
GBOW LIGHTS
H ENGINE COMPARTME NT
I DRAIN PLUGS
1 OIL PRESSURE GAUGE
2 ENGINE TEMPERATURE GAUGE
3 CLOCK
4 TACHOMETER
5 SPEEDOMETER
6 PERFECT PASS GAUGE
7 VOLTMETER
8 DEPTH FINDER
9 FUEL GAUGE
10 HORN
11 CLOCK ADJUSTMENT SWITCH
12 SPEEDOMETER ADJUSTMENT SWITCH
13 COUR TESY LIGHTS SWITCH
14 SHOWER SWITCH
15 HEATHER SWITCH
16 ACCESSORY 1
17 ACCESSORY 2
18 ACCESSORY 3
19 T OWER LIGHT SWITCH
20 T OWER LIGHT SWITCH
21 BLOWER SWITCH
22 BILGE SWITCH
23 NAV/ANCHOR LIGHTS SWITCH
24 IGNITION SWITCH
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18 19
20
21 22
23
24
A
