PARTS IDENTIFICATION
a. Control Panel
b. Remote Signal Receptor
c. Horizontal Louver Control Lever
(Fixed or manually adjusted)
d. Vertical Louver Control Lever
(Fixed or manually adjusted)
e. Panel
f. Caster
g. Handle (Both sides)
h. Air Filter (Behind the grille)
i. Upper Air Intake
j. Drain Outlet
k. Air Outlet
l. Lower Air Intake
m. Bottom Tray Drain Outlet
n. Remote Control
NOTE: Exhaust hose and other installation accessories should not be discarded.
Figure 2
n
g
h
i
j
k
l
m
a
c
d
e
f
b
Front Rear

MasterCraft MCPAC10KM Specifications

General

Brand	MasterCraft
Model	MCPAC10KM
Category	Air Conditioner
Language	English
