MasterCraft PMF300GU User Manual

11
model no. 054-7281-0 | contact us 1-800-689-9928
PARTS LIST
No. Description Qty.
1 Flange assembly 1
2 O-rings 1
3 Revolve shaft 1
4 Clutch lining 1
5 Compression spring 2
6 Orientation sleeve 1
7 Washer 1
8 Locked spring 1
9 Linkage 1
10 Spindle 1
11 Retaining ring 1
12 Ball bearing race 1
13 Shaft cover 1
14 Pendulum fork 1
15 Light cover 1
16 Light socket 1
17 Aluminum front housing 1
18 Screw 4
19 Screw 5
20 Right cover 1
21 Ball bearing race 1
22 Retaining ring 1
23 Base holder 1
24 Cam 1
25 Screw 3
26 Spanner 1
27 Lock plate 1
28 Cylindrical pin 1
29 O-rings 1
30 Bracket support 1
No. Description Qty.
31 Retaining ring 1
32 Ball bearing race 1
33 Bearing 1
34 Rotor 1
35 Bearing 1
36 Magnet ring 1
37 Transistor 1
38 Left cover 1
39 Wind baffle ring 1
40 Screw 2
41 Stator 1
42 Switch trigger 1
43 Switch lever 1
44 Waveform ring 1
45 Housing 1
46 Power cord protection cover 1
47 Speed adjustment knob 1
48 Rubber nails 1
49 Back cover 1
50 Screw 1
51 Screw 2
52 Right torsional spring 1
53 Right brush box 1
54 Left torsional spring 1
55 Left brush box 1
56 Metal detail sanding base 1
57 Brushes (one pair) 1
