OPERATING INSTRUCTIONS
INSTALL/REMOVE THE SAFETY GUARD
(fig 1)
1. Insert the ribs of the safety guard into the slots on
the trimmer head.
2. Align the holes on the safety guard with the holes
on the trimmer head, and then use the screws
(included) to lock the safety guard.
INSTALL/REMOVE THE FLOWER GUARD
(fig 2)
1. Widen the flower guard, and then insert ribs of the
flower guard into the holes on the trimmer head.
2. The flower guard can be adjusted to different
angles according to your operation.
3. Simply widen the flower guard to remove the
flower guard.
OPERATING INSTRUCTIONS
NOTICE: Before trimming or edging make sure the flower guard is locked firmly in position.
fig 1
Rib
Rib
Safety
guard
Trimmer
head
fig 2
Rib
Holes
Flower
guard
