22
model no. SC20BST | contact us 1-800-689-9928
No. Part No. Description No. Part No. Description
1 SC20BST01 Secondary Handle 32 SC20BST32 Left Swivel Arm
2 SC20BST02 Right Handle 33 SC20BST33 Angle-adjustment Button
3 SC20BST03 Right Decorative Cover 34 SC20BST34 Right Housing
4 SC20BST04 Rotation Button 35 SC20BST35 Fixing Plate
5 SC20BST05 Contact Receptacle 36 SC20BST36 Screw
6 SC20BST06 Switch Button 37 SC20BST37 Anti-dust Board
7 SC20BST07 Switch Spring 38 SC20BST38 Left Housing
8 SC20BST08 Lock-off Button 39 SC20BST39 Screw
9 SC20BST09 Spring 40 SC20BST40 Motor
10 SC20BST10 Screw 41 SC20BST41 Motor Base
11 SC20BST11 Left Handle 42 SC20BST42 Spring Washer
12 SC20BST12 Left Decorative Cover 43 SC20BST43 Screw
13 SC20BST13 Button 44 SC20BST44 Square Nut
14 SC20BST14 Internal Wire 45 SC20BST45 Base
15 SC20BST15 Micro Switch 46 SC20BST46 Eyelet Block
16 SC20BST16 Button Spring 47 SC20BST47 Feed Button
17 SC20BST17 Upper Aluminum Tube 48 SC20BST48 Spring
18 SC20BST18 Clamping Sleeve 49 SC20BST49 Nut
19 SC20BST19 Supporting Plate 50 SC20BST50 Counterweight
20 SC20BST20 Spring 51 SC20BST51 Counterweight
21 SC20BST21 Threaded Sleeve 52 SC20BST52 Spool
22 SC20BST22 Height-adjustment Collar 53 SC20BST53 Upper Cover
23 SC20BST23 Spring Line 54 SC20BST54 Flower Guard
24 SC20BST24 Sleeve 55 SC20BST55 Screw
25 SC20BST25 Aluminum Tube Limit Block 56 SC20BST56 Flat Washer
26 SC20BST26 Locking Sleeve 57 SC20BST57 Wheel
27 SC20BST27 Lower Aluminum Tube 58 SC20BST58 Wheel Carrier
28 SC20BST28 Right Swivel Arm 59 SC20BST59 Screw
29 SC20BST29 Button 60 SC20BST60 Safety Guard
30 SC20BST30 Angle-adjustment Gear 61 SC20BST61 Line Cutter
31 SC20BST31 Angle-adjustment Spring
If any parts are missing or damaged, or if you have any questions, please call the toll-free helpline at
1-800-689-9928.
PARTS LIST
