The Sound Of The Fuel Pump Running Is Audible But

The Engine Does Not Start

Cause

The system may have inadequate fuel pressure or clogged fuel ﬁlter

and/or lines.

Remedy

Take the boat to an authorized MasterCraft dealer. There are a vari-

ety of potential causes that can negatively impact fuel pressure. All

repairs require specialized tools available only to dealers.
