2016 OWNERS MANUAL / 095

Gauge Touch

Commands

Description/Action

Touch to turn cruise control ON or OFF.

Non-interactive graphic that displays a

changing of the screens.

VIDEO

The Video screen can be accessed by pressing the Video Quick

Access Key on the HV700. Press any Quick Access Key to exit this

screen.

GAUGES

The Gauge screen can be accessed by pressing the Gauges

Quick Access Key on the HV700. Press any Quick Access Key to exit

this screen.

Gauge Information

Speedometer (MPH) Water Depth (FT)

Air Temperature (F°) Water Temperature (F°)

Battery Voltage (Volts) Engine Run Time (Hours)
