4-2 L/S Precision Variable-Speed Drives Operating Manual Masterflex
Section 4
Maintenance
Fuse Replacement
Item Description
A I/O Receptacle 18-pin Round
B IEC Power Entry Module / Line Cord
C T3.15A (5 × 20 mm) Fuse - Do Not Substitute
D Power Switch - All settings are retained in memory
1. Place the power switch in the off position.
2. Disconnect the AC power input line cord from the receptacle.
3. Remove and check the fuse and replace if defective.
Figure 4-1. Fuse Replacement
A
B
D
C
