MasterForce FLEX CONNECT - Operation

Page 9
REPLACE THE BLADE
If the blade is worn out, replace it with a new
one (not provided).
1. Remove the battery pack.
2. Insert a metal rod (e.g. a screwdriver) into
the hole on the shaft under the blade to x
the blade in place.
3. Remove the nut by turning it counter-
clockwise with the wrench provided.
4. Remove the outer cup and washer.
5. Remove the old blade and replace it with a
new one.
6. Place the washer on the blade.
7. Place the outer cup on the washer.
8. Place the nut on the outer cup and tighten it
counterclockwise with the wrench provided.
OPERATION
Do not allow familiar-
ity with this product to make you careless.
Remember that a careless fraction of a sec-
ond is sufcient to inict serious injury.
Do not use any attachments or accessories
not recommended by the manufacturer of this
product. The use of attachments or acces-
sories not recommended can result in serious
personal injury.
ADJUST THE DEPTH OF CUT
1. Remove the battery pack.
2. Loosen the depth adjustment knob to
increase or decrease the depth.
3. Adjust the depth so that the blade barely
touches the ground when the machine is
held in a normal operating posture.
4. Tighten the depth adjustment knob.
5. Standing in a normal working position,
check the depth of cut again and correct if
necessary.
6. Replace the battery pack once all
adjustments are complete.
WARNING
Depth adjustment knob
Depth adjustment knob
Nut
FIG. 3
Outer cup
Wrench
Washer
Metal rod
FIG. 4
Loosen
Tighten
