ASSEMBLY INSTRUCTIONS
Axle Pins
x 4
AA
Hardware Used:
Frame Assembly
Install shims (AA) and wheels (J) to pressure
washer unit (F). Secure with cotter pins (BB).
BB
Cotter Pins
x 2
AA
AA
J
2
1
F
3
BB
FIG.1
B
F
3
2
2
1
FIG.2
AA
CC
BB
Shims
Qty. 4
Screws
Qty. 2
Cotter Pins
Qty. 2
DD
Screws
Qty. 2
AA
CC
BB
Shims
Qty. 4
Screws
Qty. 2
Cotter Pins
Qty. 2
DD
Screws
Qty. 2
Press buttons on pressure washer unit (F)
and install handle (B). Pressure washer unit
(F) will click when handle is in proper position.
Screws
Screws
x 1
x 1
Hardware Used:
Hardware Used:
DD
DD
G
A
F
DD
FIG.3
F
A
DD
M
FIG.4
Install rotary nozzle holder (G) and one side
of hose hook (A) to pressure washer unit (F).
Secure with screw (DD).
AA
CC
BB
Shims
Qty. 4
Screws
Qty. 2
Cotter Pins
Qty. 2
DD
Screws
Qty. 2
AA
CC
BB
Shims
Qty. 4
Screws
Qty. 2
Cotter Pins
Qty. 2
DD
Screws
Qty. 2
Install spray gun holster (M) and other side
of hose hook (A) to pressure washer unit (F).
Secure with screw (DD).
