MasterForce STB460 - Page 13

Page 12
ADJUST THE LENGTH OF THE
CUTTING LINE
While you operate the machine, the cutting
line gets worn shorter. You can adjust the
length of the cutting line.
1. Bump the trimmer head against the ground
while you operate the machine.
2. Line is automatically released and the cut-
INSTALL TRIMMER LINE IN THE
STRING TRIMMER HEAD
1. Line up the slots on the spool cap with the
slots on the string trimmer head.
OPERATION
FIG. 3
FIG. 4
2. Insert trimmer line through the string
trimmer head hole. Push line until it exits
through the opposite hole.
(130
mm
)
=
(130
mm
)
5.1" 5.1"
=
3. Pull the line through until there is an equal
amount of line on each side of the string
trimmer head.
4. Turn the spool cap clockwise to begin
winding the line into the string trimmer
head. Leave approximately 5 inches of line
protruding out of each side of the head.
It is recommended that 0.095" 2.4 mm)
diameter line be used for this string trimmer
head.
FIG. 5
FIG. 6
FIG. 3
FIG. 4
