Page 13
CLEANING DEBRIS AND
OBSTRUCTIONS FROM THE
STRING TRIMMER HEAD
1. Remove the battery pack.
2. Firmly press in the tabs on each side of the
spool cover.
3. Remove the spool cover from the spool
housing.
4. Remove any excess trimmer line or
obstructions from the spool.
5. Use a clean cloth to wipe away any debris
from the spool, spool cover, or spool
housing.
6. Align the tabs of the spool cover with the
posts on the spool housing. Push the spool
cover until the tabs securely snap into the
posts.
7. Replace the battery pack.
REMOVE THE STRING TRIMMER
HEAD OR RE-INSTALLING TRIM-
MER HEAD
1.
transmission hole
2. Turn the trimmer head clockwise to loosen
it. Do not remove the spacer from the shaft.
3. Reverse steps 1-2 to reinstall the same
string trimmer head.
OPERATION
FIG. 7
FIG. 8
FIG.9
