9 TECHNICAL DATA
9.1 TECHNICAL SPECIFICATIONS
Soladin 700 Web Soladin 1000 Web Soladin 1500 Web
GENERAL
Part number 130000700 130001000 130001500
Operating temp. Ambient temperature -20°C to 60°C (Full power up to 45 °C ambient)
Enclosure Aluminium enclosure, plastic front
Protection degree IP21 for indoor use
Relative humidity <90% non condensing
Safety class Class I
Inverter technology HF transformer
Cooling Intellicool
Weight 6 kg 7kg 8kg
Dimensions, hxwxd tbd 478x241x128 mm 478x241x128 mm
SOLAR INPUT (DC)
PV power range 500-900 Wp 850 - 1350 Wp 1300 - 2000 Wp
Start up power <5 W <5 W <5 W
Operating voltage 50 - 200 V 70 - 290 V 80 - 375
MPPT voltage range 65 - 160 V 100 - 230 V 145 - 300 V
Nominal voltage 140 V 205 V 220 V
Absolute maximum voltage 200 V 290 V 375 V
Overvoltage category OVC2 OVC2 OVC2
Number of inputs 1 MPP Tracker / 1 set of DC connectors
Maximum input current 9 A 9 A 12 A
Maximum short circuit current 17 A 17 A 17 A
DC protection Surge arresters class III according to IEC 61643-1
GRID OUTPUT (AC)
Voltage 230 Vac single phase +15% / -20%
Overvoltage category OVC3 OVC3 OVC3
Nominal Power 700 W 1000 W 1500 W
Maximum power 735 W 1050 W 1575 W
Maximum current 3.6 A 5.1 A 7.6 A
Maximum short circuit current 2.35 A rms for 3 periods 2.35 A rms for 3 periods 2.35 A rms for 3 periods
Frequency 50 / 60 Hz
Nominal Power factor > 0.99
Standby Power consumption < 0.5 W
EU efficiency 94.2 % 94.4 % 94.6 %
Maximum efficiency 95.1 % 95.3 % 95.4 %
AC connector 0.75 – 4 mm2 spring cage terminal block
REGULATIONS & DIRECTIVES
CE conformity Yes
Approved for use in UK, NL, DE, FR, ES, BE, DK, GR, AT, IE, BG, CZ
National grid requirements VDE0126-1-1; VDE-AR-N4105; CEI-021; RD1699; G83/1; C10/11
COMMUNICATION & MONITORING
Indicators Status LED, Power LEDs and Wi-Fi LED
Monitoring Monitoring portal (access included)
Communication Wi-Fi
16
|
EN / Soladin 700/1000/1500 Web User’s Manual
