Matfer Alphamix 2 - RECOMMENDATIONS CONCERNING THE INSTALLATION OF VARIABLE-SPEED APPLIANCES AND PERSONAL SAFETY; Wiring; Protecting your appliance

5
RECOMMENDATIONS CONCERNING THE INSTALLATION OF VARIABLE-SPEED
APPLIANCES AND PERSONAL SAFETY
These recommendations apply to machines
equipped with an induction motor and a single-
phase wobbulator.
NB :
- The electrical circuit and the protective devices
must comply with national regulations.
- The machine must be wired in by a qualified
electrician
Protecting your appliance
• Like all electronic devices, wobbulators include
components that are sensitive to electrostatic
discharges (ESDs). Before conducting any work
on these wobbulators, technicians must therefore
rid themselves of electrostatic charges.
• The machine must be disconnected from the
mains supply before any internal connection
operations are carried out.
Wiring
• You must connect the machine to a 200-240V/50
or 60 Hz single-phase* alternating current supply
with an earthed socket. A higher voltage will
destroy the wobbulator.
• The earthed socket ensures operator safety.
You can begin by consulting the characteristics of
your appliance in the table below:
* Except for specific three-phase 200-240 V models sold
in Japan.
Appliance Mains supply
Conductor
Cross-section
(mm
2
)
GFCI (Ph + N)
Gauge (A) Threshold (mA)
Alphamix 2
(5 Litres)
230 V - 240 V
50 Hz
single-phase
1.5 B16 ≥ 30
Alphamix 2
(8 Litres)
220 V - 240 V
50 or 60 Hz
single-phase
1.5 B16 ≥ 30
