Matrix A7xe - Assembly Step

24 25
QTY
4
QTY
4
SOCKET HEAD CAP SCREW
(M10x1.5Px25L)
10.9 GRADE MIN IMUM
SPRING WASHER
(Ø10.2xØ20x2.0T)
ASSEMBLY STEP 2
RED HARDWARE BAG CONTENTS
ALL
MODELS
ALL
MODELS
ASSEMBLY STEP 1
ASCENT TRAINER®
SUSPENSION ELLIPTICAL™ TRAINER
