Matrix A7xe - Page 16

30 31
ALL
MODELS
ALL
MODELS
QTY
8
QTY
8
SOCKET HEAD CAP SCREW
(M8x1.25Px20L)
10.9 GRADE MINIMUM
QTY
2
SOCKET HEAD CAP SCREW
(M8x1.25Px45L)
10.9 GRADE MINIMUM
SPRING WASHER
(Ø8.2xØ15.4x2.0T)
QTY
2
SCREW
(M5x0.8Px16L)
QTY
4
SCREW
(M5x0.8Px12L)
QTY
4
SCREW
(M5x0.8Px16L)
BLUE / BLACK HARDWARE BAG CONTENTS :
ASSEMBLY STEP 7
QTY
8
QTY
8
SOCKET HEAD CAP SCREW
(M8x1.25Px20L)
10.9 GRADE MINIMUM
QTY
2
SOCKET HEAD CAP SCREW
(M8x1.25Px45L)
10.9 GRADE MINIMUM
SPRING WASHER
(Ø8.2xØ15.4x2.0T)
QTY
2
SCREW
(M5x0.8Px16L)
QTY
4
SCREW
(M5x0.8Px12L)
QTY
4
SCREW
(M5x0.8Px16L)
QTY
4
QTY
4
SOCKET HEAD CAP SCREW
(M8x1.25Px25L)
10.9 GRADE MINIMUM
SPRING WASHER
(Ø8.2xØ13.5x2.0T)
WHITE HARDWARE BAG CONTENTS :
ASSEMBLY STEP 8
ASCENT TRAINER®
SUSPENSION ELLIPTICAL™ TRAINER
