ASSEMBLY STEP 9
PINK HARDWARE BAG CONTENTS :
QTY
1
SCREW
(M5x0.8Px16L)
NOTE:
Be careful not to pinch any wires while tightening screw.
ASSEMBLY STEP 10
QTY
2
SCREW
(M5x0.8Px16L)
PINK HARDWARE BAG CONTENTS :
10.1
9.2
10.1 10.2 FINAL
