Matrix A7xe - Page 18

34 35
ALL
MODELS
ASSEMBLY STEP 11
PINK HARDWARE BAG CONTENTS :
QTY
2
SCREW
(M5x0.8Px16L)
11.1
11.2
11.1 11.2
ASSEMBLY STEP 12
ASSEMBLY COMPLETE!
QTY
5
SCREW
(M5x0.8Px16L)
QTY
1
ADAPTOR PLATE
PINK HARDWARE BAG CONTENTS :
5x, 7x, 7xe CONSOLE ONLY
5x, 7x, 7xe CONSOLE
3x, 3xe CONSOLE
ALL
MODELS
