Matrix A7xi - Page 10

1918
ALL
MODELS
ALL
MODELS
QTY
4
QTY
4
QTY
2
SOCKET HEAD CAP SCREW
SPRING WASHER
ALB UNITS ONLY:
PHILLIPS HI-LO SCREW
WHITE HARDWARE BAG CONTENTS :
ASSEMBLY STEP 8
ASCENT TRAINER®
SUSPENSION ELLIPTICAL™ TRAINER
3X ASCENT TRAINER
HANDLEBAR SHOWN
ASSEMBLY STEP 9
PINK HARDWARE BAG CONTENTS :
QTY
1
SCREW
(M5x0.8Px16L)
NOTE:
Be careful not to pinch any wires while tightening screw.
ASCENT LOWER BODY
