Matrix A7xi - Page 9

1716
ALL
MODELS
ALL
MODELS
ASSEMBLY STEP 6
QTY
8
QTY
8
SOCKET HEAD CAP SCREW
(M8x1.25Px20L)
10.9 GRADE MINIMUM
QTY
2
SOCKET HEAD CAP SCREW
(M8x1.25Px45L)
10.9 GRADE MINIMUM
SPRING WASHER
(Ø8.2xØ15.4x2.0T)
QTY
2
SCREW
(M5x0.8Px16L)
QTY
4
SCREW
(M5x0.8Px12L)
QTY
4
SCREW
(M5x0.8Px16L)
BLUE / BLACK HARDWARE BAG CONTENTS :
ASSEMBLY STEP 7
QTY
8
QTY
8
SOCKET HEAD CAP SCREW
(M8x1.25Px20L)
10.9 GRADE MINIMUM
QTY
2
SOCKET HEAD CAP SCREW
(M8x1.25Px45L)
10.9 GRADE MINIMUM
SPRING WASHER
(Ø8.2xØ15.4x2.0T)
QTY
2
SCREW
(M5x0.8Px16L)
QTY
4
SCREW
(M5x0.8Px12L)
QTY
4
SCREW
(M5x0.8Px16L)
MX14_AEALB3x_5x_7xe_7xi_OM_Rev1_1.indd 16-17 6/4/14 11:24 AM
