Matrix A7xi - Page 7

1312
QTY
4
QTY
4
SOCKET HEAD CAP SCREW
(M10x1.5Px25L)
10.9 GRADE MINIMUM
FLAT WASHER
(Ø10.2xØ20x2.0T)
ASSEMBLY STEP 2
RED HARDWARE BAG CONTENTS
ALL
MODELS
ALL
MODELS
ASCENT TRAINER®
SUSPENSION ELLIPTICAL™ TRAINER
ASSEMBLY STEP 3
PINK HARDWARE BAG CONTENTS
QTY
2
SCREW
(M5x0.8Px16L)
