Matrix AURA Series Quick Start Guide

AURA SERIES (G3-S31) SEATED ROW
UNPACKING (G3-S31) SEATED ROW
Thank you for purchasing a MATRIX Fitness product. Your AURA SERIES (G3-S31) SEATED ROW is inspected before it is packaged. It is shipped in multiple
pieces to facilitate the compact packaging of the machine. Prior to assembly, conrm all the components by matching them with the exploded diagrams. Carefully
unpack the unit from this box and dispose of the packing materials in accordance with your local laws.
CAUTION
To avoid injury to yourself and prevent damage to the frame components, be sure to have proper assistance removing the frame pieces from this box. Please be
sure to install the equipment on a stable base, properly level the machine and leave at least two feet of clearance to enter and exit the machine.
TOOLS REQUIRED FOR ASSEMBLY (not included)
3MM L-Shaped Allen Wrench 10MM L-Shaped Allen Wrench
4MM L-Shaped Allen Wrench Phillips Screwdriver
5MM L-Shaped Allen Wrench 8MM Open-End Wrench
6MM L-Shaped Allen Wrench 17MM Open-End Wrench
8MM L-Shaped Allen Wrench Guide Rod Lubrication
If any items are missing please contact your country’s local MATRIX dealer for assistance.
0 mm 10 20 30 40 50 60 70 80 90 100 110 120 130
Step 2
Weight Stack Detail
Weight Plate
Step 3
F03
F06
L14
Allen Head Cap Screw
Attachment Plate
Flat Washer
4
2
4
Item Description Qty
Belt Routing Detail
Flat Washer
Attachment Plate
Belt
Allen Head Cap Screw
Belt
L14
F06
F03
Step 4
B79
B64
B70
B51
Q06
Q07
Screw (M8x18L)
Screw (M8x30L)
Screw (M4x12L)
Internal Tooth Lock Washer
Rubber Shield Spacer
Rubber Tip Weight Shield Bolt
2
2
6
6
6
6
Item Description Qty
Accessory Detail
B51 x6Upper Cover x2
B70 x6
Lable Plate
B64
Towel / Water
Bottle Holder
B79
Q06
Q06
Q06
Q06
Q07
Q06
Q07
Q06
Q07
Q07
Q07
Q01
Q07
Step 1
J08 Screw (M10x35L) 4
Item Description Qty
Upholstery Detail
J08
