Matrix COSEC PATH DCFE User Manual

Assigning IP Address and other
Network Settings
Ÿ Open a Web browser on your computer.
Ÿ Enter the IP address of the PATH Controller
(default: http://192.168.50.1) , in the address bar of the browser
and press the Enter key on your computer keyboard.
Ÿ When prompted, enter the login credentials for the Door.
Ÿ Click OK. On the Door Web page, select the Network tab and
enter the required network configuration such as Door IP
address, Server IP address etc.
Ÿ Save the Settings.
Default Username: Admin
Default Password: 1234
Power ON
Blue ON/OFF
Online
Light Blue ON
Offline
Red ON
Degraded Mode
Orange ON
LED Indication
Device Status
LED Status Indicators
Technical Specifications-Door Cntroller
G E N E R A L
User Capacity
Credential
Supported
Input Power
Communication
Built in WiFi
Built in Bluetooth
Types of Card
Buzzer
Interface
Power Output
COSEC PATH DOOR Controller Variants
50,000
Ethernet & RS-485
RS - 232 and Wiegand
EM Prox
Card &
Finger-
print
Card
Card &
Finger-
print
Card &
Finger-
print
LED
Yes (6hrs of battery backup on COSEC PATH BBU &
COSEC PATH PSBB)
Tamper Detection
R E A D E R
DCFE
DCCE
DCFM
DCCM
DCFI
DCCI
SPECIFICATIONS
5,00,000
Event Buffer
12 VDC @2A
Battery Backup
Yes (IEEE 802.11 a/b/g/n)
HID i-class
Internal 12 VDC @0.250A
Yes
Yes
Yes (2 LEDs with Tri-colour)
22
21
Template
Storage Capacity
Yes
Card
Card
SFM 5030: 9600 (1:N)
SFM 6030: 25,000 (1:N)
MIFARE
R

Matrix COSEC PATH DCFE Specifications

General

Brand	Matrix
Model	COSEC PATH DCFE
Category	Controller
Language	English
