Matrix COSEC PATH DCFE - Page 9

DCCX
Cables
DCFX
Cables
DCFX
DCCX
Connect cables and lead them through the bottom opening of
Duct Box as shown below.
Step 4
1. Fix the Top-Cover to Base Plate by sliding Mounting Hook of top-
cover into the Mounting Slot of base plate.
2. Tighten screws at the bottom as shown on Next Page.
Step 5
18
17
