Matrix CUBE User Manual

24-Bit /192kHz High Performance Stereo Audio Processor MATRIX
- 6 -
PROBLEMS CAUSES SOLUTIONS
Power OFF z Unplugged into a proper AC
z Power is turned off
Make sure the power
cable is connected to a
proper AC and turn it ON
No Signal
z Digital input cable disconnected or
no input signal
z Digital signal outputs abnormally
z Make sure the digital
input cable is linked up
correctly
z Check the digital signal
output
No analog output Analog port disconnected Connect the audio cable
correctly
No Headphone
output
z It might be working under the DAC
Mode
z Volume has been turned to
minimum
z Switch to the INTERNAL
mode
z Adjust the volume
Common Malfunction
Common breakdowns might be caused by an interrupted AC power. Or the device is
troubled by static electricity. Under these circumstances, turn it off and unplug the
main power at least for a minute, then reconnect and restart.
● Technical Specifications
Digital Interface:
Input：
OPTICAL： Sealed Optical Input
Sampling Rate : 32kHz~192kHz
BNC ： Standard BNC 75 ohm
Sampling Rate : 32kHz~192kHz
USB ： Standard USB Connector
Sampling Rate : 44.1kHz~48kHz
Output：
Coaxial Output:
Standard RCA jack
Sampling Rate: 32kHz~192kHz，
Supports AC-3, DTS data output
Output Level
:0.5Vp-p (75 οhm)
Analog Interface:
RCA Output Level： 2.0VRMS
RCA Input Impedance： 47kΩ
Frequency Response： 20Hz~20KHz
SNR： 109dB
Dynamic Range： 107dB
Distortion： ＜0.0005%（1KHz）

Matrix CUBE Specifications

General

Brand	Matrix
Model	CUBE
Category	Computer Hardware
Language	English
