Matrix CXM

7/16 | Version: 2 | Revision Date: 3/6/2020 | Revised by: JS Matrix CX Cycles
TOUCH RESPONSE TOC
Sensitive, Hard, Press
NO TOUCH
Console doesnt accept
touch input
Remove console
from bike & open
rear cover. Check
that touchscreen
ribbon cable is
connected to socket
along bottom edge
BUTTON
Console button doesnt
do anything
Remove console
from bike & open
rear cover. Check
that button cable is
connected to socket
J8, lower left corner
Touch hardware is
not field-
serviceable.
Replace console.
Additional Information
• Sweat, cleaner, water, and other contaminants on the touchscreen frequently cause apparent
failures. Properly cleaning the touchscreen is commonly all that’s required to resolve.
• Spraying cleaner directly on the screen is not recommended. Spray cleaner on a cloth and wipe
the screen with it.
