Matrix ENDURANCE TOUCH PREMIUM LED User Manual

7
C
H
H
C
I
F
G
ENGLISH
1
4
3
7
6
2
8
5
5
Hardware Qty
F
G
Bolt
Flat Washer
2
2
6
Hardware Qty
H
C
Bolt
Flat Washer
4
4
7
Hardware Qty
H
C
I
Bolt
Flat Washer
Screw
4
4
2
ASSEMBLY COMPLETE
1
2
3
4
5
6
7
8
MCB Communication
Extension Power Wire
Ethernet
Coax
Ground Wire
Emergency Stop
TV Power
Console Connect Wires
Torque Value
F - 16 Nm / 12 ft-lb
30 Nm / 22 ft-lb
Torque Value
40 Nm / 29 ft-lb
Torque Value
H - 40 Nm / 29 ft-lb

Matrix ENDURANCE TOUCH PREMIUM LED Specifications

General

Brand	Matrix
Model	ENDURANCE TOUCH PREMIUM LED
Category	Treadmill
Language	English
