Matrix Endurance

6
D
C
TOOLS REQUIRED:
F 4 mm Allen Wrench
F 6 mm Allen Wrench
F Flat Wrench (15mm/17mm 325L)
F Phillips Screwdriver
PARTS INCLUDED:
F 1 Main Frame
F 1 Rear Stabilizer Tube
F 1 Front Stabilizer Tube
F 1 Rear Frame Handle
F 1 Rear Frame Cover
F 1 Console Mast
F 1 Console Handlebars
F 2 Handlebar Covers
F 1 Seat Frame
F 1 Water Bottle Pocket
F 1 Seat Base
F 1 Seat Back
F 1 Hardware Kit
F 1 Power Cord (packaged with console)
Console sold separately
A
B
1
Hardware Qty
A
B
Bolt
Spring Washer
8
8
2
Hardware Qty
C
D
Bolt
Screw
2
2
RECUMBENT CYCLE ASSEMBLY
ENGLISH
