Matrix G3-MS50 User Manual

16
4.4 ROUND PAD REPLACEMENT
1) Pull the old round pad from the tube (Figure A).
2) Push the new round pad into the tube (Figure B).
Figure A Figure B
4.5 SEAT PAD REPLACEMENT
1) Using 6MM L-Shaped Allen Wrench to take off 3 bolts of the old seat pad (Figure A)
2) Replace new pad and fix the 3 bolts (Figure B).
Figure A Figure B
1) Using 6MM L-Shaped Allen Wrench to take off 4 bolts of the old seat pad (Figure A)
2) Replace new pad and fix the 4 bolts (Figure B).
Figure A Figure B

Matrix G3-MS50 Specifications

General

Brand	Matrix
Model	G3-MS50
Category	Fitness Equipment
Language	English
