5
ENGLISH
Z10x6
Z25x6
Z15x2
Z10x4
Z24x4
Z15x4
7 5
Hardware Qty
Z15
Z24
Z10
Bolt (M10x25L)
Spring Washer (M10)
Flat Washer (M10)
4
4
4
ASSEMBLY
ASSEMBLY COMPLETE
6
Hardware Qty
Z15
Z25
Z10
Bolt (M10x25L)
Hex Bolt (M10x25L)
Flat Washer (M10)
2
6
6
